[FMX] Des navigateurs de données (TBindNavigator) en couleur

Un billet blog de SergioMaster

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
unit ColoredBindNavigator;

interface

 uses System.Classes, System.UIConsts,System.UITypes,
      FMX.Bind.Navigator, Data.Bind.Controls;

/// range TNavigateButton in three groups
const   NavigatorScrollings = [nbFirst, nbPrior, nbNext, nbLast,nbRefresh];
        NavigatorValidations = [nbInsert, nbDelete, nbEdit, nbPost, nbCancel,
                                nbApplyUpdates];
        NavigatorCancelations = [nbDelete,nbCancel,nbCancelUpdates];

type

  TNavigatorColors = record
    scroll : TAlphacolor;
    update : TAlphacolor;
    cancel : TAlphacolor;
    class operator initialize (out Dest: TNavigatorColors);
    class operator finalize (var Dest: TNavigatorColors);
  end;

  TColorNavButton = class helper for TBindNavButton
    /// set the color of the Tpath.fill.color property
    procedure setcolor(c : TAlphaColor);
    /// apply the custom colors corresponding to the TNavigateButton type
    /// Three groups NavigatorScrollings,NavigatorValidations,NavigatorCancelations
    /// see const part
    procedure ApplyColorStyle(customcolors : TNavigatorColors);
  end;

  TColorBindNavigator = class helper for TCustomBindNavigator
    /// initialize and apply custom colors
    function customcolors(scrollcolor, Updatecolor, cancelcolor : TAlphaColor) : TNavigatorColors; overload;
    function customcolors(colors : TNavigatorColors) : TNavigatorColors; overload;
  end;

implementation

{ TColorNavButton }
procedure TColorNavButton.ApplyColorStyle(customcolors : TNavigatorColors);
var defaultstylecolor : TAlphaColor;
begin
inherited;
with Self do
  DefaultStylecolor:=FPath.Fill.Color;
if (TNavigateButton(Self.index) in NavigatorScrollings)
    AND (customcolors.scroll<>TAlphacolors.Alpha)
// todo test    AND (customcolors.scroll<>DefaultStyleColor)
 then Setcolor(customcolors.scroll);
if (TNavigateButton(Self.index) in NavigatorValidations)
    AND (customcolors.update<>TAlphacolors.Alpha)
 then Setcolor(customcolors.update);
if (TNavigateButton(Self.index) in NavigatorCancelations)
    AND (customcolors.cancel<>TAlphacolors.Alpha)
 then Setcolor(customcolors.cancel);
end;

procedure TColorNavButton.setcolor(c: TAlphaColor);
begin
with Self do
   FPath.Fill.Color:=c;
end;

{ TNavigatorColors }
class operator TNavigatorColors.finalize(var Dest: TNavigatorColors);
begin
// nothing to do
end;

class operator TNavigatorColors.initialize(out Dest: TNavigatorColors);
begin
Dest.scroll:=TAlphaColors.Alpha;
Dest.update:=TAlphaColors.Alpha;
Dest.cancel:=TAlphaColors.Alpha;
end;


{ TColorBindNavigator }
function TColorBindNavigator.customcolors(scrollcolor, Updatecolor,
  cancelcolor: TAlphaColor) : TNavigatorColors;
begin
result.scroll:=scrollcolor;
result.update:=updatecolor;
result.cancel:=cancelcolor;
for var i := 0 to  self.ControlsCount-1 do
      TBindNavButton(Self.Controls[i]).ApplyColorStyle(result);
end;

function TColorBindNavigator.customcolors(
  colors: TNavigatorColors): TNavigatorColors;
begin
for var i := 0 to  self.ControlsCount-1 do
      TBindNavButton(Self.Controls[i]).ApplyColorStyle(colors);
end;

end.

1
2
3
4
5
6
7
8
9
10
11
12
13

interface

uses
  System.SysUtils, System.Types, System.UITypes, System.Classes, System.Variants,
  FMX.Types, FMX.Controls, FMX.Forms, FMX.Graphics, FMX.Dialogs,
  Data.Bind.Controls, FMX.Controls.Presentation, FMX.StdCtrls, FMX.Layouts,
  Fmx.Bind.Navigator, FMX.Memo.Types, FMX.ScrollBox, FMX.Memo, FMX.Objects,
  FireDAC.Stan.Intf, FireDAC.Stan.Option, FireDAC.Stan.Param,
  FireDAC.Stan.Error, FireDAC.DatS, FireDAC.Phys.Intf, FireDAC.DApt.Intf,
  FireDAC.Stan.StorageBin, Data.Bind.Components, Data.Bind.DBScope, Data.DB,
  FireDAC.Comp.DataSet, FireDAC.Comp.Client,
  ColoredBindNavigator;

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
type
  TForm1 = class(TForm)
    BindNavigator1: TBindNavigator;
    btnDark: TButton;
    Memo1: TMemo;
    FDMemTable1: TFDMemTable;
    BindSourceDB1: TBindSourceDB;
    Label1: TLabel;
    StyleBook1: TStyleBook;
    Button1: TButton;
    procedure btnDarkClick(Sender: TObject);
    procedure FormCreate(Sender: TObject);
    procedure Button1Click(Sender: TObject);
  private
    { Déclarations privées }
     Colors : TNavigatorColors;
  public
    { Déclarations publiques }
  end;

1
2
3
4
5
6

procedure TForm1.FormCreate(Sender: TObject);
begin
CustomColorsNavigator :=true;
colors:=BindNavigator1.customcolors(Talphacolors.blue,Talphacolors.Green,Talphacolors.Red);
end;

1
2
3
4
5
6
7
8
9

procedure TForm1.btnDarkClick(Sender: TObject);
begin
 colors.scroll:=Talphacolors.darkBlue;
 colors.update:=Talphacolors.darkGreen;
 colors.cancel:=TAlphacolors.darkRed;
 for var i := 0 to  BindNavigator1.ControlsCount-1 do
      TBindNavButton(BindNavigator1.Controls[i]).ApplyColorStyle(colors);
end;
